Low-Level Access Swift Up 4.5

Low-Level Access Swift Up 4,5 represents a simple, safe and efficient alternative to ladders and scaffolds. Swift Up 4,5 is a scissor lift which combine high load capacity and large working platform. Swift Up 4,5 is perfect for installation, finishing and maintenance works. Simple to use, Swift Up 4,5 gives operators the advantage of an ergonomic working position, so they can perform their duties safely.

Product characteristics

Indoor

Indoor

Even ground

Even ground

Electric

Electric

Application fields

Finishings

Finishings

Logistic / Retail / Industry

Logistic / Retail / Industry

Maintenance & renovation

Maintenance & renovation

Sporting & other events

Sporting & other events

Swift Up 4.5

Presentation

  • Tiny machine, high productivity
  • Low size, high agility
  • Low maintenance, easy to use

Specifications

Tiny machine, high productivity

Tiny machine, high productivity

  • Ultra compact design: fit through single doors, elevators...
  • Narrow turning radius to fit with confined spaces constraint
  • Lightweight to work on sensitive grounds or in multi-story projects
Low size, high agility

Low size, high agility

  • Small platform to work in tiny spaces
  • Heavy tools and material transportable at once : platform capacity up to 240 kg
Low maintenance, easy to use

Low maintenance, easy to use

  • No set up time, just push the machine where you want to use it
  • Maintenance free battery

Working height 4.5 m
Platform height 2.5 m
Lift capacity 240 kg (1 pers.)
Platform size 1.04 m x 0.57 m
Length 1.2 m
Width 0.7 m
Height - stowed 1.78 m
Wheel base 0.9 m
Ground clearance 5 cm
Tyres size 150mm x 48mm
Turning radius - Inside 0 m
Turning radius - Outside 1.2 m
Weight 315 kg
Motion Push-Around - Manuel
Tilt 1.5 °
Battery 12V DC - AGM
4,5
Swift Up 4.5
Swift Up 4.5

  • Manual horizontal motion (push around)
  • Electrically driven lifting
  • Maintenance free AGM battery
  • Battery charger > 15 Ah
  • Battery level indicator on lower control box
  • Overload indicator on upper control box
  • Battery charge indicator
  • 2 fixed wheels - 2 castor wheels
  • Mechanical wheel lock
  • Swing door
  • Mobile upper control box
  • Tilt indicator on upper control box
  • Emergency lowering descent
  • Hour meter
  • Forklift pockets
  • Charger plug with dedicated storage box
