Presentation
- Tiny machine, high productivity
- Low size, high agility
- Low maintenance, easy to use
Specifications
Tiny machine, high productivity
- Ultra compact design: fit through single doors, elevators...
- Narrow turning radius to fit with confined spaces constraint
- Lightweight to work on sensitive grounds or in multi-story projects
Low size, high agility
- Small platform to work in tiny spaces
- Heavy tools and material transportable at once : platform capacity up to 240 kg
Low maintenance, easy to use
- No set up time, just push the machine where you want to use it
- Maintenance free battery
| Working height | 3.8 m |
| Platform height | 1.8 m |
| Lift capacity | 240 kg (1 pers.) |
| Platform size | 1.04 m x 0.57 m |
| Length | 1.2 m |
| Width | 0.7 m |
| Height - stowed | 1.72 m |
| Wheel base | 0.9 m |
| Ground clearance | 5 cm |
| Tyres size | 150mm x 48mm |
| Turning radius - Inside | 0 m |
| Turning radius - Outside | 1.2 m |
| Weight | 270 kg |
| Motion | Push-Around - Manual |
| Tilt | 1.5 ° |
| Battery | 12V DC - AGM |
| 3,8 |
- Charger plug with dedicated storage box
- Manual horizontal motion (push around)
- Electrically driven lifting
- Maintenance free AGM battery
- Battery charger > 15 Ah
- Battery level indicator on lower control box
- Overload indicator on upper control box
- Battery charge indicator
- 2 fixed wheels - 2 castor wheels
- Mechanical wheel lock
- Swing door
- Mobile upper control box
- Tilt indicator on upper control box
- Emergency lowering descent
- Hour meter
- Forklift pockets
In addition, Haulotte provides
- A call center for a rapid online troubleshooting
- Mobile experts for on-site intervention
- A fully equipped workshop for complex repairs
- Haulotte diag a universal diagnostic tool
- An online documentation accessible 24/7
- Maintenance support for your machines (including labor, travel expenses, and original parts)
- Annual management of your equipment maintenance
- Optimization of the total cost of ownership
- Free access to all technical documentation for Haulotte machine models.
- Information on equipment
- Manuals for safe use of machines
- All documents are ready to download
- Accessible 24/7
