Presentation
- High performance & rough terrain capacities
- Full electric drive
- Maintenance and service-oriented
- Extended duty cycles
Specifications
High performance & rough terrain capacities
- Platform capacity of 750 kg
- Drive axle with manual locking rear differential increases ground traction
Full electric drive
- Silent & clean operations
- Versatile use: outdoor / indoor
- Smooth & proportional movements
Maintenance and service-oriented
- Activ’Screen: on-board configuration & diagnostic interface
- Easy access to components
- Haulotte Activ’Energy Management takes care of your battery
Extended duty cycles
- Multiple charging modes including optional accelerated charge
- Optional & removable, low fuel consumption Range Extender (Stage 5)
| Working height | 15 m |
| Platform height | 13 m |
| Max. drive working height | 15 m |
| Lift capacity | 750 kg (4 pers.) |
| Lift capacity on the extension | 225 kg |
| Platform length | 3.93 m |
| Platform length - extended | 4.9 m |
| XL platform length (option) | 4.94 m |
| XL platform length - extended (option) | 7.5 m |
| Length - extension | 0.98 m |
| Lenght - extension XL option | 1.28 m |
| Platform width - outside | 1.89 m |
| Height - stowed | 3.05 m |
| Height - guardrails lowered | 2.25 m |
| Overall width | 2.3 m |
| Length | 4.4 m |
| Wheelbase | 2.76 m |
| Ground clearance | 30.7 cm |
| Drive speed | 5 km/h |
| Gradeability | 45 % |
| Tilt (longitudinal / lateral) | 5° / 3° |
| Turning radius - outside | 6.75 m |
| Tyres | 830 x 285 mm |
| Batteries | 8 x 6 V - 435 Ah (C20) |
| Weight | 7 518 kg |
- 4 wheel drive
- Mechanical axle with manual locking rear differential
- Outriggers with centralized or individual controls
- One platform extension
- Two drop bar entries
- Folding handrails
- Haulotte Activ'Energy Management: smart battery management system & manual centralized watering
- AC motors
- 48V battery pack
- Haulotte Activ'Screen
- Automatic battery water-filling system
- Double swing gate entries
- Standard platform with dual extensions (5.89 m)
- XL platform with dual extensions (7.5 m)
- Range Extender (5.2 kW - Stage 5)
- Accelerated charger (380 V)
- Cold & arctic weather kits
- Non marking tires
- Material handling rack
- AC power to platform plug (110 / 230 V)
- Platform lighting
- Work light
- Telematics holder & predisposition
- Telematics solutions
- Haulotte Activ'Shield Bar
