Presentation
- Maximum productivity
- Excellent rough-terrain capabilities
- Optimized cost of ownership
- Optimal safety
Specifications
Maximum productivity
- 360° continuous rotation (PRO model only)
- 4 wheel steering for more agility (PRO model only)
Excellent rough-terrain capabilities
- Oscillating axle for a very good ground grip (PRO model)
- Differential lock (hydraulic) to optimize crossing capacity
- Climbing ramps up to 45%
Optimized cost of ownership
- Simple and reliable engine (<19kW, does not require a particulate filter)
- Simplified hydraulic architecture thanks to mechanical axles
- Sherpal ready for maximized usage and to generate additional revenue (optional)
Optimal safety
- Haulotte Activ'Shield Bar: anti-crushing system (standard PRO model)
- Haulotte Activ'Lighting System: load and unload the machine in low visibility conditions (standard PRO model)
| Working height | 20.5 m |
| Platform height | 18.5 m |
| Horizontal outreach | 11.9 m |
| Up and over clearance | 8.5 m |
| Lift capacity | 250 kg (2 pers.) - option 350 kg |
| Platform size | 1.80 x 0.8 m |
| Length - stowed | 8,6 m |
| Width | 2.43 m |
| Height - stowed | 2.47 m |
| Storage / transport length | 6.16 m |
| Storage / transport height | 2.98 m |
| Platform rotation | 180° ( -90° / +90°) |
| Turntable rotation | 355° non continuous |
| Tailswing | 42 cm |
| Wheelbase | 2.5 m |
| Ground clearance | mini 30 cm / maxi 36 cm |
| Tilt | 4° - option 6° |
| Drive speed | 0.5 - 5 km/h |
| Maximum wind speed rating | 45 km/h |
| Gradeability | 45 % |
| Tires - solid rough terrain | 910 x 355 mm |
| Turning radius - outside | 5.2 m |
| Power source | KUBOTA, TIER 4 final : Stage V, China IV, Diesel: 18.5 kW |
| Weight | 9180 |
| Ground clearance - mini | 30 cm |
| Ground clearance - maxi | 36 cm |
- Haulotte Activ’Shield Bar (standard PRO model)
- Haulotte Activ'Lighting System (standard PRO model)
- Haulotte Stop Emission System
- Haulotte Activ’Screen
- 4 wheel drive and 4 wheel steering (standard PRO model) / 4 wheel drive and 2 wheel steering (standard RTJ model)
- Oscillating axle (PRO model only)
- 360° continuous rotation (PRO model only)
- Simultaneous and proportional movements
- Modular standard basket
- Swing out engine tray for ease of maintenance
- Access to the MyHaulotte multi-service portal
- Universal telematic plug
- 12 V battery / electrical control system
- Rotating beacon
- Upper control box protection cover
- Permanent limited slip differential
- Hydraulic generator 3.5 Kw, 6Kw and 9Kw
- USB port
- Large basket 2.44 x 0.91 m
- Swing door entry gate
- Air line to platform
- Cold weather kit
- Glazier kit
- Flashing light
- Sherpal telematics subscription
- Non-marking tires
- Haulotte Extra Reach
