One of the most versatile machines in the industry: these lightweight self-propelled lifts have working heights from 55 to 61 feet and low ground pressure for sensitive surfaces such as landscaping, designed concrete and interior uses. Hydraulic outriggers set-up in less than 30 sec for safe work on uneven ground.

Product characteristics

Indoor / Outdoor

Indoor / Outdoor

Uneven ground

Uneven ground

Electric

Electric

Application fields

Landscaping

Landscaping

Sporting & other events

Sporting & other events

HLA16 PX

Specifications

Access like never before

Access like never before

  • Hydraulic outriggers and automatic leveling allow operation in under 30 seconds
  • High performance 4WD and light weight provide access to places larger and heavier machines cannot go
  • Easily transported on a trailer with no commercial driver’s license requirement
  • Dual power source (DC / Gas) allows for indoor/outdoor use
Optimum performance

Optimum performance

  • 4,000 Watt generator
  • Air / water lines to platform
  • 110V GFI protected power to the platform

Working height 15.54 m
Platform height 13.72 m
Horizontal outreach (from centerline) 8.23 m
Horizontal outreach (from edge of footpad) 6.4 m
Up and over height 6.33 m
Lift capacity 227 kg
Length - stowed 5.54 m
Width stowed 1.67 m
Height stowed 2.01 m
Wheelbase 2.67 m
Ground clearance 15 cm
Platform size 1.52 x 0.76 m
Outrigger footprint 3.76 x 3.45 m
Turntable rotation 350° non-continuous
Jib - length 1.3 m
Jib - Vertical motion 150° (+70 / -80)
Drive speed 7.6 km/h
Gradeability 45%
Turning radius - inside (2WS) 3.05 m
Turning radius - inside (4WS) 1.62 m
Tyre size 26 x 12 Bar lug
Batteries 4 x 6V 245 Amp-hr
Engine 31 hp gas Kubota
Weight 2358 kg
HLA16 PX
HLA16 PX
HLA16 PX

  • Hydraulic outriggers
  • Bar lug tires
  • Inboard 25 amp charger
  • Spring applied hydraulic released brakes
  • Tilt alarm / sensor
  • Easy to use controls with logically positioned buttons
  • Dual power system
  • Battery condition indicator
  • Hour meter
  • 4,000 W generator
  • 110V GFI protected outlet to platform and base
  • Air and water lines to platform
  • Self-leveling platform
  • Automatic leveling system (leveling capability 12.5°)
  • 4 wheel steering (standard on HLA19PX)

  • Turf tires
  • Flashing beacon
  • Fluorescent tube caddy
  • Tool tray
